Ratchet Cable Cutter

The China-made Lingkai wholesale ratchet cable cutter is used to cut a variety of wire ropes, including Cu-Al, steel wire ropes, steel strand, maritime, armored, and ACSR cables. The Ningbo Lingkai ratchet cable cutter facility produces tools in various sizes suitable for both overhead line and subterranean operations.

Send Inquiry

Product Description

Because of the following benefits, Lingkai's bulk ratchet cable cutter is sold in over 20 countries, particularly the USA and Europe.

The handle of the ratchet cable cutter can be fully retracted, and its extended operation saves more work. It features a high-quality alloy steel blade that is dependable and long-lasting. It is also easy to remove the buckle and return the knife halfway. Labor-saving operation using ratchet propulsion.

Our sturdy ratchet cable cutter lasts longer because of our strict control over the raw materials and processes.

advanced heat treatment ——scientific microstructure——uniform hardness——practiced CNC process——reliable raw material

Ratchet cable cutter datasheet

J40	<=300mm2 Cu-Al cable, 1000 pairs of communication cables	346x120x38mm; 1.15kgs
J52	<=D50mm Armored cable	397x165x54mm; Elongation 568x165x54mm;3.1kgs
J75	3x120mm2 or D75mm below Cu-Al cable 3600pairs ofcommunication cables	416x200x55mm; Elongation 587x200x55mm;3.5kgs
J95	3x185mm2 or D95mm below Cu-Al cable	446x248x55mm; Elongation: 620x28x55mm,5.7 kgs
J50	150mm2 ACSR 1440mm2 steel strand	400x158x52mm, Elongation 570x158x52mm;3.2kgs
J130	D130mm below CA-AL cable	530x330x63mmm Elongation:700x330x63mm, 9,3kgs
J100	3X300mm2, 100m armored cable	482x270x59mm Elongation 655x270x594mm;6.5kgs
J13	150mm2 ACSR, 720mm2 steel strand	345x125x46mm Elongtaion 515x125x46mm,1.95kgs
J30	100MM2 ACSR 630mm2 steel strand	405x160x64mm; Elongation: 515x160x64mm;3.6kgs
J25	150mm2 ACSR; 800mm2 steel strand	390x160x55mm Elongation:560x160x55mm;3.45kgs
J40	Single core 300mm2 CU-AL cable Armored cable	240mm, 1.0kgs
XLJ-D-500A	D40mm CU-AL cable Armored cable	240mm ,1,1 kgs
CC400	D40mm CU-AL cable Armored cable	355X125X40MM 1.2kgs
CC 325	240mm2 CU-Al cable	260x115x35mm, 0.55kgs
XLJ-G-32A	D 35mm ACSR; D40mm Cu-Al and armored cable, and D8-16mm steel wire.	330x140x55mm; Elongation: 400x140x55mm, 1.9kgs
XLJ-G-40	D 40MMACSR and armored D15mm steel strand	350x150x60mm Elongation 410x150x60mm, 3.5 kgs
