Electric Hydraulic Pump Station

Power line construction and subterranean cable crimping sites frequently use electric hydraulic pump stations that serve as power sources for equipment. Plumbing tools, hydraulic compression heads, and remote control hydraulic crimping tools are a few examples. The 0.75 KW, 1.2 KW, and 0.4 KW electric hydraulic pump station in Ningbo, Lingkai, China, is manufactured.

Send Inquiry

Product Description

A high-quality Electric Hydraulic Pump Station it is equipped with an electromagnetic valve control to draw pistons in any position. It has two high- and low-speed stages for quick oil output. Turbine oil absorption could ensure maximum, effective oil volume.

The pressure safety valve in Electric Hydraulic Pump Station has an overpressure unit to avoid overpressure damage and a pressure release of 700 kg/cm2. High pressure is for driving pistons, and lower pressure is for piston reset. And oil fitted with quick coupling could be ordered in any length and with PT3/8’’ thread.

Electric Hydraulic Pump Station

Model	Oil outlet way	Pressure rating	Power	Oil delivery	Reservoir capacity	Weight
EHP-70AS	Single hole	700/10000kgf/cm2/psi	0.75kw	Low:5 High:0.8(cc/stroke)	8000cc	29kgs
EHP-700ZS	Two hole	700/10000kgf/cm2/psi	0.75kw	Low:5 High:0.8(cc/stroke)	8000cc	30kgs
EHP-63A	Single hole	700/10000kgf/cm2/psi	0.75kw	Low:5 High:0.8(cc/stroke)	6000cc	28kgs
SH-700	Single hole	700/10000kgf/cm2/psi	1.2kw	Low:5 High:0.7(cc/stroke)	2000cc	12kgs
SH-700A	Single hole	700/10000kgf/cm2/psi	0.40kw	Low:3.5 High:0.5(cc/stroke)	2000cc	15kgs
