Automatic Come Along Clamps for Aluminum Conductor

Our Automatic Come Along Clamps for Aluminum Conductor are designed to correct the tension when mounting wire and sagging aluminum conductors that are in stock. Aluminum conductors are strung on overhead transmission lines using aluminum alloy come along clamps. Our Automatic Come Along Clamps for Aluminum Conductor are made with a unique jaw that protects the aluminum conductor's surface while providing a secure hold on the conductor. Every clamp has a three safety factor.

Send Inquiry

Product Description

Automatic come along clamps for aluminum conductor made in China Ningbo Lingkai is made of the Aluminum magnesium alloy compact, to replace the aluminum alloy, it has more strength than before type. The customized Automatic come along clamps for aluminum conductor it is per the ACSR diameter size to see the opening max.

Automatic come along clamps for aluminum conductor can specified the max range cross of ACSR diameter, technically we will not advise to cross more than 5mm, due to the more the less hold force of the Automatic come along clamps for aluminum conductor, and it will increase the risk in the operation.

Newest Automatic come along clamps for aluminum conductor is to maintain temporary tension until it can be permanently terminated. Some Automatic come along clamps for aluminum conductor with hook type needed, it is beyond the LGJ ACSR 400, along with the hook in the Along Clamp For Conductor it can make sure the force much more bigger, and make the whole operation much more easily for the worker, also safety factors will be good !

Customized along Clamp for Conductor please find us freely any time

Item number	Model	Rated Load （KN）	Applicable Conductor	Max Open （MM）	Weight （KG）
13221	SKL-7	7	LGJ25-70	14	1.0
13222	SKL-15	15	LGJ95-120	18	1.4
13223	SKL-25	25	LGJ150-240	24	3.0
13224	SKL-40	40	LGJ300-400	32	4.0
13225A	SKL-50C	50	LGJ500-630	36	6.6
13224A	SKL-40A	40	LGJ400	32	4.3
13225	SKL-50A	50	LGJ500	34	7.0
13226	SKL-50B	50	LGJ630	36	7.3
13227	SKL-60	60	LGJ720	38	9.2
13228	SKL-70	70	LGJ900	42	14.0
13229	SKL-80	80	LGJ1000	45	18.0
13229A	SKL-80A	80	LGJ1120	48	18.0
